Product Information

Overview

Embedded AI features that provide the next evolution in the user experience. Ensure crystal clear voice calls with AI-powered audio on loud plant floors. And warehouse workers get pinpoint accuracy with the AI-enabled touchscreen-even with thick gloves.

Specifications

Physical Characteristics

Dimensions 10.8 in W x 7.8 in L x 0.7 in H
(275mm W x 199mm L x 18.3mm H)
Weight 2.6 lbs (1,200g)
Display 10.1 in. WUXGA (1920 x 1200)—1,000 nits; optically bonded to touchpanel; Contrast Ratio 1000:1
Touchpanel Capacitive multi-touch, Corning® Gorilla® Glass, AI Powered Touch Control for automatic optimization and precise interaction with included passive stylus, MPP 2.0 Active Pen Compatible
Connectivity Docking connector (charge and data); keyboard connector; one USB 3.1 Type A port; two ThunderboltTM 4/USB4 Type C ports
Interface Ports and Expansion Docking connector (charge and data); Keyboard connector; 1 x USB 2.0 (back I/O – host only)
Notifications Audible tone; 1 multi-color LED
Audio Stereo speakers and two microphones; audio headset supported through USB port or Bluetooth; speaker/microphone support
Buttons Power; Scan; Up/Down (programmable); three programmable keys
External Scanner Support HID via USB and Bluetooth®; scanner configuration with Zebra 123Scan, Zebra Scanner SDK
Performance Characteristics

CPU Intel® Core™ Ultra 5 125U
Intel® Core™ Ultra 5 135U (vPro®)
Intel® Core™ Ultra 7 155U
Intel® Core™ Ultra 7 165U (vPro®)
Operating System Windows® 11 Professional 64 bit,
Windows® 11 IoT Enterprise LTSC
Memory 8, 16, 32 GB LPDDR5 RAM
Storage 128 GB, 256 GB, 512 GB, 1 TB, 2 TB tool-less user removable M.2 2230 PCIe NVMe SSD
256 GB, 512 GB tool-less user removable M.2 2230 Opal SED SSD
User Environment

Operating Temp. -20F to +145F (-29C to +63C)2
Storage Temp. -40F to +158F (-40C to +70C)
Humidity 5% to 95% non-condensing
Drop Specifications Exceeds MIL-STD-810H
5 ft. (1.5m) to concrete
Meets MIL-STD-810H
6 ft. (1.8m) to plywood over concrete
Sealing IP66 per IEC 60529
Shock/Vibration MIL-STD-810H Method 514.8 and 516.8
Thermal Shock MIL-STD-810H: 40F to +158F (-40C to +70C)
Electromagnetic Compatibility MIL-STD-461G, MIL-STD-464D (HERO Certification), EN 55032, EN 55024
Electrostatic Discharge IEC61000-4-2, ± 15 kV air discharge; ± 8 kV contact; ± 8 kV indirect
Salt Fog MIL-STD-810H, 48h of 5% solution at +95F (+35C)
Solar Radiation EN/IEC 60068-2-5 solar radiation spectral energy distribution; 1120 W/m2 at display surface; Environmental temperature: +104F (+40C); irradiation duration: 24 hours
Impact IEC EN 60079-15, Ball drop; 5 Joules on touch screen
Hazardous Location Certification Class 1 Division 2 (select configurations)
Vehicle Certifications E-Mark Europe 12V system ECE Regulation No. 10 Rev. 6 (Tablet with keyboard in docking station)
Power

Charging 45W USB Power Delivery 3.0 through either USB-C port, or optional dock
Battery Standard capacity: 36Wh
Extended capacity: 72Wh
True Hot Swap Minimum 60 seconds over the full operating temperature range with internal super capacitor
Battery Charge Time Standard battery: 2.5 hrs from 0% to 100% with 45W power supply
Extended battery: 5 hrs from 0% to 100% with 45W power supply

Sensors

Ambient Light Sensor Automatically adjusts display brightness
Magnetometer eCompass
Motion Sensor 3-axis gyroscope; 3-axis accelerometer
Fingerprint Sensor Windows® Hello fingerprint reader
Data Capture

Optional Integrated Scanner SE55 1D/2D Advanced Range Scan Engine with IntelliFocus™ technology
Rear Camera 13 MP autofocus; flash LED generates balanced white light
Front Camera 5 MP RGB with mechanical privacy shade
Infrared camera for Windows® Hello support
Wireless LAN

Radio IEEE 802.11-2020 and select amendments (selected feature coverage)
IEEE 802.11a, b, d, e, g, h, i, k, n, r, u, v, w, ac, ax, be; Fine Timing Measurement based on 802.11-2016, 802.11az HW readiness
Data Rates Up to 5.8 Gbps; 2×2 MU-MIMO; 320 MHz channels; 4096-QAM; 6 GHz, 5 GHz, and 2.4 GHz bands
Operating Channels 2.4 GHz: Channel 1-13; Bandwidth: 20/40 MHz
5.0 GHz: Channel 36-165; Bandwidth: 20/40/80 MHz
6.0 GHz: Channel 1-221; Bandwidth 20/40/80/160/320 MHz
Security and Encryption WPA3 personal and enterprise including WPA2 transition mode; 802.1X EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0 -MSCHAPv2 (EAP-SIM, EAP-AKA, EAP-AKA’), 128-bit AES-CCMP, 256-bit AES-GCMP
Fast Roam 802.11r Fast Transition, 802.11k
Certifications Wi-Fi 7 Technology support, Wi-Fi CERTIFIEDTM 6 with Wi-Fi 6E, Wi-Fi CERTIFIED a/b/g/n/ac, WMM, WMM-Power Save, WPA3, PMF, Wi-Fi Direct, Wi-Fi Agile Multiband, Wi-Fi Location R2 HW readiness
Wireless PAN

Bluetooth Bluetooth® 5.4 (Class 1), Bluetooth® Low Energy (BLE)
NFC Reader/Writer: ISO 14443 –A-B, MIFARE, FeliCa®, ISO 15693, NFC Forum Tag Types 1 to 4
Wireless WAN (ET65W only)

SIM Slots 1 x eSIM; 1 x Nano SIM
Frequency Bands 5G NR: n1/2/3/5/7/8/12/13/14/18/20/25/26/28/29/30/38/40/41/48/66/70/
71/75/76/77/78/79
LTE-FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/
30/32/66/71
LTE-TDD: B34/38/39/40/41/42/43/48
LTE LAA: B46
UMTS WDCMA: B1/2/4/5/8/19
LTE/5G Private Networking Supported
GNSS GPS, GLONASS, BDS (BeiDou), Galileo, QZSS
Security Features

Discrete TPM v2.0; NIST BIOS compliant; FIPS 140-2 Validated; Common Criteria certified; Windows® Hello front facing camera; Windows® Hello fingerprint reader (optional); contactless NFC Smart Card reader; insertable Common Access Card (CAC) Smart Card reader (optional); Absolute Persistence® technology embedded in BIOS*; Kensington cable lock slots available on the tablet only or the tablet with the keyboard attached.

*Requires software and activation

General Certifications

TAA compliant
FirstNet® (US only)
Thunderbolt™ 4
Peripherals and Accessories

Accessories include: vehicle dock; keyboard; CAC/Smart Card reader; RFID reader; 2-slot battery charger; active stylus; carrying accessories — handstrap, kickstand, shoulder strap and handle

*Specifications are subject to change without notice
